Automatic Multi-Function Packaging Machine For Cup Box Packing & Book Cover

Brand Name : Longxingsheng

Model Number : LS-450plus

Certification : CE, ISO9001

Place of Origin : China

MOQ : 1

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 15sets/month

Delivery Time : 7-15 work days

Packaging Details : With paper,film and by wooden crate.

Product name : LS-450plus Multi-Function Packaging Machine For Paper Box Packing & Book Cover & Cellphone Box

Type : Multi-Function packaging machine

Working speed : 15-38 pcs/min

Application : Case positioning and gluing

Dimension(L*W*H) : L5980*W3185*H2104

Weight of machine : 2141kg

Contact Now

LS-450plus Multi-Function Packaging Machine For Paper Box Packing & Book Cover & Cellphone Box

Introduction:

LS-450plus is a multi-function visual positioning machine. It is able to positioning the rigid box and hardcover. also can do paper lining, one machine with many functions, and the working model is able to be changed by one button. The visual positioning system is able to be upgraded. Moreover, this machine also can be upgraded to an automatic line in the future if needed.

Automatic Multi-Function Packaging Machine For Cup Box Packing & Book Cover

Equipped with dual cameras, the cameras are located on both sides of the central position of the conveyor belt. The camera position has been calibrated before leaving the factory. If there is any deviation, you can adjust the camera position by adjusting the upper camera "mounting plate". After the camera takes a picture, the system recognizes the color difference of the photo for positioning. If the surface paper and the surface paper conveyor belt are similar in color, it can be solved by changing the belt color.
The machine has two conveying systems, which are widely applicable. One conveys boxes, and the other conveys album covers and book covers (hardcover/book covers). The machine has a key to switch modes. It can be used to make boxes or leather cases (hardcover/book cover), and to change the working mode, it only needs to switch with one button, which is easy to operate and saves working time. The machine not only guarantees the customer in terms of operating efficiency, but also solves the customer's concerns about how the machine operates.

The machine is multifunctional, not only used by manufacturers who produce boxes, but also for factories that produce book covers, it is the best choice for customers

Advantages:
  • Flexible
Can connect with four sides wrapping machine to make the hardcover
Can work with box wrapping machine to make rigid box
Can make special box, such as slant side box (videos are available)
  • High speed
With 2 sets LS-F7 box wrapping machine, the speed of machine can make around 131000 pcs per day
  • Save setting time
Only need 7 minutes when change product mode
One bottom to change case to box
No stop working when change different size, because one F6 for presetting and another one can keep working
Optional function:
  1. Glue Viscosity Device : Automatic detecting the hot melt glue thickness.
  2. Air Operated Double Diaphragm Pump: Applied in white glue pumping.
  3. Bottom sucker hardcover feeding device: Special design for feeding hardcover, to avoid scraping hardcover.

Specifications of LS-450plus:
TypeLS-450plus
Paper size (Max)L800*W600mm
Paper size (Min)L135*W100mm
Max box sizeL600*W400*H120mm
Min box sizeL80*W65*H15mm
Book cover (Max)L750*W450mm
Book cover (Min)L150*W100mm
Paper thickness100-350g/㎡
Paper stacking height280mm
Motor power / voltage7.5kw/380v, 3 phase
Heating power8kw/380v, 3 phase
Air supply10L/min 0.6Mpa
Working speed15-45 sheets/min
Machine dimensionL5980*W3180*H2100mm
Weight of machine2100kg





































Company profile:
Automatic Multi-Function Packaging Machine For Cup Box Packing & Book Cover
Dongguan Longxingjian Intelligent Equipment Co.,Ltd

We are located in world manufacturer city----Dongguan City, Guangdong Province. The former compay name is Dongguan Longxingsheng Machinery Co.,Ltd.

We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery's research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.

We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.

Our service:

Automatic Multi-Function Packaging Machine For Cup Box Packing & Book Cover

Pre-sale service:

* Inquiry and consulting support.
* Sample testing support.
* Factory visit.

After-sale service:

* Machine installation and training in customer factory.
* Engineers available to service machinery overseas.
* Free machine parts replacement during warranty.
* Whole life of machine service.
